Mahsulot kodi:
1223302
Mahsulot kodi:
1223302
Yog‘ turi:
Talablarga mos:
ZF TE-ML 05C
ZF TE-ML 12C
ZF TE-ML 16E
ZF TE-ML 21C
Texnik spetsifikatsiyalarga mos:
MIL-L-2105 D
API:
Tolerances:
RAVENOL Sperrdiff.-Getr.-Oel LS 90 is locking differential hypoid gear oil that meets the extremely stringent requirements in differential gears and differential lock.
RAVENOL Sperrdiff.-Getr.-Oel LS 90 ensures good adhesion, high pressure-resistant lubricating film and offers excellent "limited slip" (LS) properties against unwanted slip-slip properties. Greatly offset hypoid gear pairs are also under severe operating conditions effectively protected against wear.
Application Note
RAVENOL Sperrdiff.-Getr.-Oel LS 90 GL-5 was specially developed for use in differential with high requirements on differential with differential lock.
Characteristics
- Extremely high load carrying capacity
- Excellent wear protection by EP agents
- Excellent "limited slip" – Features
- Excellent resistance to aging
- High oxidation resistance even under high thermal stress
- Good foam / air separation and behave well at high speeds
- Neutrality towards non-ferrous metals and seals
- Excellent viscosity-temperature behavior
Ko‘proq ko‘rsatish
Kamroq ko‘rsatish
Ishlab chiqaruvchining rasmiy saytida mahsulot sahifasi: ravenol.de
Kategoriyalar:
Texnik xususiyatlar
| Parametr | Qiymat | Audit |
|---|---|---|
| Brand | RAVENOL | |
| Viskozite | 90 | |
| Zichlik 20°С da, g/cm³ | 889 | EN ISO 12185 |
| Rang | tan | տեսողական |
| Viskozite 100°С da, mm²/s | 17.6 | DIN 51562-1 |
| Viskozite 40°С da, mm²/s | 177.3 | DIN 51562-1 |
| Viskozite indeksi VI | 108 | DIN ISO 2909 |
| Brookfield usuli bo‘yicha viskozite -12°C da, mPa*s | 12.400 | ASTM D2983 |
| Qotish harorati, °C | -30 | DIN ISO 3016 |
| Yong‘in chiqish harorati, °C | 214 | DIN EN ISO 2592 |
| Misga nisbatan korroziya testi, 121°С / 3 soat | 1b | ASTM D130 |
