RAVENOL Turbinenöl T 68

Mahsulot kodi: 1330356
Qisqa ishlab chiqaruvchi kodi: 1330356-208
To‘liq ishlab chiqaruvchi kodi: 1330356-208-01-999
Shtrix-kod: -
Eskirgan shtrix-kodlar:
Eskirgan artikullar:
Narx:
-

RAVENOL Turbinenöl T 68

Mahsulot kodi: 1330356
Yog‘ turi:
Talablarga mos:
Alstom HTGD 90117
BS 489:1999
Siemens TLV 9013 04
Texnik spetsifikatsiyalarga mos:
DIN 51515-1 L-TD
ISO 6743-0

RAVENOL Turbinenöl T 68 is produced for the lubrication of gas and steam turbines as well as turbo compressors with and without transmission according to the specifications of DIN 51 515-2.

RAVENOL Turbinenöl T 68 is based on high quality mineral base oils with agents to increase the corrosion protection and aging resistance.

RAVENOL Turbinenöl T 68 is a universal mineral oil for turbines of especially chosen refined base oils with a natural high viscosity index. So-called “metal deactivators” are added to the turbine oil in addition to the normal additives in order to guarantee the excellent characteristics.

Application Note

RAVENOL Turbinenöl T 68 is used in fixed gas and steam turbines as well as electrical machines or machines driven by steam turbines like generators, compressors, pumps and transmissions.

RAVENOL Turbinenöl T 68 can also be used for the lubrication of hydraulic systems, compressors, gear transfers and bearings in case of problems of the contamination with water because a high protection against rust and oxidation is requested.

Characteristics

  • an excellent thermic and oxidative stability
  • an excellent viscosity temperature behaviour
  • a high and stable viscosity index
  • a very good oxidation stability also at very high temperatures
  • a good protection against corrosion of Ferro and non Ferro metals
  • an excellent water separation behaviour
  • a very good air separation behaviour which excludes foam formation as far as possible
  • a low pour pointa good corrosion behaviour
  • an excellent water separation behaviour / demulsifying behaviour
Ko‘proq ko‘rsatish Kamroq ko‘rsatish

Texnik xususiyatlar

Parametr Qiymat Audit
Kenglik, mm 580
Uzunlik, mm 580
Balandlik, mm 885
Og‘irlik, kg 198.171
Viskozite 68
Brand RAVENOL
Zichlik 20°С da, g/cm³ 868 EN ISO 12185
Viskozite 100°С da, mm²/s 9 DIN 51562-1
Viskozite 40°С da, mm²/s 69 DIN 51562-1
Viskozite indeksi VI 104 DIN ISO 2909
Qotish harorati, °C -30 DIN ISO 3016
Yong‘in chiqish harorati, °C 262 DIN EN ISO 2592
